Schema Management
Uploading a Schema
Make sure the uploaded schema is used in the Producer / Consumer application in exact same form. If you are uploading a schema that has not references to other schemas you can upload the avsc file or if you are uploading a schema that has references to other schemas you can upload the compiled schema file. If you use a plugin such as the avro-maven-plugin for schema maintenance, make sure to upload the source schema files. |
-
Click on the schema Upload icon.
-
Upload the schema as a text file (avsc format). The Avro syntax will be validated as soon as the file has been uploaded.
-
Add the version for the schema
-
If you are uploading the first version of this schema, be sure to add a description
-
Any authenticated user can upload a schema for their tenant.
Error scenarios
Duplicate schema
An attempt at uploading a duplicate schema for a tenant is rejected with an error message containing the duplicated version as shown below:
Incompatible schema
In some situations you want to force the use of an incompatible schema. As of Axual 2021.3 it is possible to force apply a schema.
When selecting an incompatible schema, the following modal is shown.
Click "Confirm" if you want to force updating the schema to the incompatible one.
make sure to inform anyone who is using your topic, especially in an acceptance or production environment |
